Advanced Automotive Electric Circuit Training System

Switch board: Approx. over 2,500 X 800 X 1,700 mm
-Attached circuit : Ignition, charging, circuit of indicating direction and emergency light, horn, door lock, head light, washer, wiper, starting, fuel, sidelight, antenna, audio system, various sensors and switch, ECU,key box, combination switch, relay box, battery, combination switch relay, fuse box and fuel tank
-Steering handle, surge tank, throttle body, injector and AFS light attached
-Battery and charger
-Charging Device: with extra Charger or HP motor operation
-1,500cc Engine Type
