DETAIL PRODUK
CNC Milling Trainer
Kompetensi Keahlian :
Teknik Pemesinan
Deskripsi :
Pelatihan penggunaan mesin Milling CNC sama seperti aslinya, dan hasilnya dapat diaplikasikan secara langsung.
Axis Motor and Drive Servo Approx. motor with Servo Drives
X Axis/Y Axis/Z Axis 300 mm/ 225 mm/ 250 mm
Feed Rate 0-10,000 mm/min
Table Size approx. 575 x 225 mm
T Slot approx. 3 x 10 x 50 Load on Table approx. 140 Kg
Vice Type Pneumatic/ Manual Spindle Motor Capacity approx. 2 HP
Spindle Nose Taper ISO 30/BT 30
Spindle RPM 100 - 4000 RPM
Controller Control System PLC Based Control System Positioning approx. 0.005 mm
Repeatability +- 0.005 mm
Resolution approx. 0.001 mm
Tool Changer Automatic Automatic/ Manual Quick Tool Change
No. of Tools 8
Maximum Tool Length/ Dia approx. 40 mm/16 mm
Actuation Hydraulic (Compressor not required)
Real Time tool path simulation Provided
Lubrication Automatic
Coolant Automatic
Power Supply 415V, +-2% 50 Cycles, 3 Phase
Axis Motor and Drive Servo Approx. motor with Servo Drives
X Axis/Y Axis/Z Axis 300 mm/ 225 mm/ 250 mm
Feed Rate 0-10,000 mm/min
Table Size approx. 575 x 225 mm
T Slot approx. 3 x 10 x 50 Load on Table approx. 140 Kg
Vice Type Pneumatic/ Manual Spindle Motor Capacity approx. 2 HP
Spindle Nose Taper ISO 30/BT 30
Spindle RPM 100 - 4000 RPM
Controller Control System PLC Based Control System Positioning approx. 0.005 mm
Repeatability +- 0.005 mm
Resolution approx. 0.001 mm
Tool Changer Automatic Automatic/ Manual Quick Tool Change
No. of Tools 8
Maximum Tool Length/ Dia approx. 40 mm/16 mm
Actuation Hydraulic (Compressor not required)
Real Time tool path simulation Provided
Lubrication Automatic
Coolant Automatic
Power Supply 415V, +-2% 50 Cycles, 3 Phase
Tag:
#DAK Alat SMK 2023
Anda menginginkan produk ini?
Hubungi Kami Sekarang
