Concrete Compression Strength Test Equipment

Hydraulic System.
Control system.
System including digital servo valve, high-precision sensors, controllers and software, high control precision and reliability. Meet GB, ISO, ASTM and other standards for cement, mortar, concrete and other materials testing requirements.
Max load 2000KN
Test force measuring range 4%- 100%FS
Test Force showed the relative error ≤indicating value±1% Test Force Resolution approx. 0.03KN
Hydraulic pump rated pressure approx. 40MPa
Upper and lower bearing plate size approx. 320 x 260mm Maximum distance between the upper and lower plate 330mm Piston diameter approx. φ250mm
Piston stroke approx. 50mm
Motor Power approx. 0.77 kW
