Elektronika and Digital Trainer

Minimal konfigurasi :
• 29 unit resistors 2W: 1x 10 R, 2x 22 R, 1x 33 R, 2x 100 R, 1x 220 R, 1x 330 R, 2x 470 R, 1x 680 R, 3x 1K, 2x 2K2, 2x 4K7, 3x 10K, 3x 22 K, 2x 47 K, 2x 100 K, 1x 1 M
2 unit potentiometers: 1K, 10K, unit NTC: 4k7 / 0.25W -25°C-
+125°C, 1 unit VDR: S10K11, 1
unit toggle switch, 1 unit Diac: DB3, 1 unit mounted transformer: 2 coils with 600 windings, 1 coil
with 200 windings, 1 separable core, retainer for transformer core,8 unit transistors: 1x BC 140- 16, 1x BC 547B, 1x BC 160-16, 1x BC 140-16, 1x 2N 3820, 1x FET 2N 3819, 1x 2N 2647, 1x BS 250
1 unit thyristor: S4003L, 1 unit
triac: Q4004L, 1 unit inverter, 2 unit AND, 2 unit OR, 1 unit NAND, 1 unit NOR, 1 unit XOR, 1 unit hex switch and analogue source 0 – 5 V, 1 unit LED bar
graph, 1 unit counter, 1 unit 7- segment display, 1 unit RS flip-
flop, 2 unit JK flip-flops, 2 unit shift registers, 1 unit full adder, 4mm safety lab cables, red, blue
Buku manual penggunaan
