Hydraulic Landing Gear Trainer

Dapat digunakan untuk pelatihan up and down landing gear hydraulic power system.

- Hydraulically operated retractable L/G with operational strut
- Hydraulically operated landing gear door
- Sequencing is controlled through squat switches and sequencing valves
- All components are mounted on the display panel to provide a clear view to the students.
- Can be used to demonstrate a typical hydraulic system operation in addition to the landing gear operation
- Flap and landing gear controls can be mechanical or electrical (customer's choice)
- Wing section included
- Hydraulically operated flap with electrical indication system
- The system includes electrical motor dan a mechanical pump with all associated components (pressure regulator, relief value, check values, reservoir and filter assy.)
- Full function brake system with parking brake operation
- Landing gear indication includes: gear up, gear down and in-transit
- Throttle lever with associated components completes the warning circuit of gear up warning horn
- Emergency hand pump
- Accumulator
- Powder coated finish for durability
- Swivel casters with brakes for full mobility and safe positioning
- System powered by either 220vac 50hz or 110 vac 60hz, single phase.
- Computer-based training (CBT) included.
