Hydraulic Universal Testing Machine

Untuk mengetahui sifat mekanis dari suatu logam terhadap tarikan dimana sifat mekanis tersebut antara lain meliputi batas kekuatan tarik, kekenyalan, pertambahan panjang dan pengecil luas penampang

- Table model
- Maximum Capacity: 10kN 10kN
- Effective test width: 420 mm 420
- Crosshead Stroke: 1100 mm 1200
- Effective stroke: 580 mm 580
- Crosshead Speed: 0,05~1000mm/min 0.05-1000
- Crosshead speed accuracy: ±0.2% 0.20%
- Crosshead random speed: 0.01mm/min step in crosshead speed range 0.01mm
- Crosshead return speed: 1000mm/min or 500mm/min 500 mm/min
- Load measurement accuracy: ±1% of reading (within range of 1/1
- 1/500 of load cell rating) same
- Load range: Fully automatic range switching (up to 128 folds) 128 fold
- Sampling speed: 1msec 1msec
- Safety function for overload: Provided overload: Provid
- Stroke limiter: Upper/lower limit 2 points 2 poin
