Intermediate Electrical Maintenance Skill Training & Assessment

SPESIFIKASI :

• Input power：AC380V, 50Hz/60Hz, Three-phase, five wires Protection device action when capacity current below 1.5 KVA, 30mA AC volt meter with indicator 450V
• AC power : Three phase output, 0～220V/2A adjustable AC power output, Transformer
• AC output: equipped with emergency stop button.
• DC stabilized power supply : 1.25～30V/2A accuracy of adjustment 1%, Provide 0~190V/2A adjustable
• DC power Digital meter : AC digital volt meter, precision class 1.0; AC digital ammeter, measurement range 0~5A , precision class 0.5; DC digital volt meter, measurement range 0~300V, input resistor 10 MΩ; DC digital ammeter, measurement range 0~5A, precision class 0.5; Commutation diode 1N5408
• Part list: Platform : Aluminium Power control : Aluminium structure, provide three-phase, single phase and DC power; Training components
  •  Plate equipped with thermal relay, AC contactor, Button indicator lamp and terminals; Training components
  • Plate equipped with screw-type fuse, straight fuse, low-voltage circuit breaker, time relay, AC contactor and terminals; Training components
  • Plate equipped with screw-type fuse, change-over switch, solenoid, cross switch, position switch; Training components
  • Plate equipped with AC overcurrent relay, DC low current relay, DC over-current relay, rectifier; Training components
  • Plate equipped with lamp socket,ballast and starter; Training components
  • with three groups 100Ω×2/1.3A resistance. Electric wiring training components : Fix circuit board Three-phase asynchronous motor: 380V 180W Cable : K4, K2 User Manual
