KNX/EIB Compact Trainer

Bangunan modern dicirikan oleh pencahayaan yang cerdas dan solusi pendingin ruangan.
Membangun sistem otomasi dan sistem bus memainkan peran penting di sini.
Papan kompak KNX / EIB EduTrainer digunakan untuk menjelaskan penggunaan teknologi ini.

Konfigurasi minimal :
– Input voltage: 1 AC/230 V AC (50 Hz), short circuit and overload protection
– Phase display
– Output for the connection of additional KNX/EIB EduTrainer® modules
– Output voltage: 1 AC/230 V AC
– Integrated power supply unit 30 V DC 0.16 A
– USB interface

– 4/4-fold switching output/binary input
– 2-fold louvre actuator
– 2-fold dimming actuator
– 4-fold universal binary I/O
– 4-fold multi-function pushbutton sensor with 8 pushbuttons
– 2-fold multi-function pushbutton sensor with 4 pushbuttons, room temperature controller including setpoint and actual value input and display
– Integrated simulation panel with 14 colour LEDs, some dimmable
– KNX system connector for bus connection
– Connection via 4 mm and 2 mm safety connectors
– Front plate: 399 x 297 mm
– Control console housing with rubber feet for use in A4 frame or on tabletop
– Buku Petunjuk Penggunaan
