DETAIL PRODUK

Metalurgy Microscope
Kompetensi Keahlian :
Teknik Pengecoran Logam
Deskripsi :
Untuk melihat struktur dari potongan specimen logam.
Achromatic Objective 5X, 10X, 40X
Wide Field Plane-Scope Eyepiece with scale of Crosshair and approx. 0.1 mm and Wide,Field Plane-Scope Eyepiece;
Total Magnification: 50 - 400X ;, Articulated Free Trinocular Head, Interpupillary Distance : 55- 7Smm; 30° Inclined, 360° Rotatable;
The Adjustable Height range of the vertical Tube: approx. 30mm;
Revoving Round Stage: approx. Ø160mm. 360° Rotatable and Graduated 1o Increments, Minimum
Resolution 6' When Using Venire
Scale Center Adjustable;
Ø2-Ø30mm Iris Diaphragm And approx. Ø32 Filter;
Coaxial Coarse And Fine Focusing Adjustable;
Condenser: N.A.1.25;
Coaxial Coarse And Fine Focusing Adjustable Mechanism: approx. 35mm, Precision: approx. 0.002mm;
Achromatic Objective 5X, 10X, 40X
Wide Field Plane-Scope Eyepiece with scale of Crosshair and approx. 0.1 mm and Wide,Field Plane-Scope Eyepiece;
Total Magnification: 50 - 400X ;, Articulated Free Trinocular Head, Interpupillary Distance : 55- 7Smm; 30° Inclined, 360° Rotatable;
The Adjustable Height range of the vertical Tube: approx. 30mm;
Revoving Round Stage: approx. Ø160mm. 360° Rotatable and Graduated 1o Increments, Minimum
Resolution 6' When Using Venire
Scale Center Adjustable;
Ø2-Ø30mm Iris Diaphragm And approx. Ø32 Filter;
Coaxial Coarse And Fine Focusing Adjustable;
Condenser: N.A.1.25;
Coaxial Coarse And Fine Focusing Adjustable Mechanism: approx. 35mm, Precision: approx. 0.002mm;
Tag:
#DAK Alat SMK 2023
