Power Electric and Transformer
Peralatan praktek pembelajaran ini berisi peralatan untuk belajar kelistrikan dan tenaga listrik meliputi DC power circuit, AC single phase, AC 3 phase.
Minimal konfigurasi :
1 unit Capacitive Load, Nominal Voltage: 230 V/50 Hz, Maximum Voltage: 440 V,
Capacitance Value Accuracy: ± 5%, 1x AC Transformer Bank dalam A4 modul termasuk 3 independent power transformer,
Primary rating: 400 V AC, max. 0.25 A each transformer,
Secondary rating: 400/230 V AC, max. 0.25 A each transformer, 100 VA each transformer,
4 unit AC Transformer single phase transformer 4 unit primary and secondary sides dibuat,
Primary rating (2 windings), Secondary rating (2 windings),
Nominal power: 240 VA,
Thermistor: 10 kΩ, type 2, Protected against short circuit and overload circuit,
Protected against short circuit and overload,
Phase sequence indicator,
Lockable Emergency Stop.
Beban kapasitif dan indikator urutan fase.
Buku panduan penggunaan, Eksperimen modul
