Ship Bridge Simulator

Minimum Hardware of Ship
Bridge
Simulator:
− 1 set of PC for instructor
− 2 sets of Server for
Visualization System
with 7 unit LED Display
minimum 55” UHD / 4K
(represent real
225 degree of view)
− 1 set of PC for RADAR ARPA
Display − 1 set of PC for ECDIS
Display.
− 1 set of PC for GMDSS Display
− 1 set of PC for Conning Display
− 1 set of PC for Navigational
Aids Display.
− 1 set of PC for Overhead
Nautical Instruments Panel
Display with 3
units Monitor.
− 1 set of Steering Console
− 1 set of Sound Library− 1 unit
of Printer
− 1 unit of Networking System
− 1 set of CCTV
− 1 set of Instrument Console
and Visual, including: mock up bridge /
console and
visual frame (represent real 225
degree of
view)
− 1 unit of Chart table
− 1 unit of Fire extinguisher
Minimum
Software of Ship Bridge
Simulator:
− Instructor Software − Instructor
Main
Display Module
− GMDSS Module
− RADAR ARPA Repeater Module
− ENC Chart Module − Trainee
Software
− Visualization System Module
− RADAR ARPA Module
− ECDIS Module
− GMDSS Module
− Conning Module
− Navigational Aids Module
− Overhead Nautical Instruments
Panel Module
