Simulator Jaringan
1. WAN Trainer
Terdiri dari :
Routing Layer
Protocol Module
(PC1) x3 - Intel Pentium
Processor 3,0 GHz - Motherboard + PSU - RAM 2 GB - HDD 500GB - DVD RW - LAN Card (On
board) - Ethernet Card PCI
Express - Cooling Fan
Application Layer
Protocol Module
(PC2) x3 - Intel Pentium
Processor 3.0 GHz - Motherboard + PSU - RAM 2 GB - HDD 500GB - DVD RW - LAN Card (On
board) - Cooling Fan WAN Trainer Micro
controller Module x3 - Controller Board
with integrated KVM
and Splitter - Switching power
supply
Keypad and LCD
Display Control Panel
x3 - Keypad & LCD
Display Micro
Controller Board - LCD Display panel
20 x 4 - Keypad 4 x 4
Network & I/O Panel
x3 - Mikrotik Router
Board - Media Converter - Easy Smart Switch
5-port - Barel 5-port - 150Mbps Wireless
Router, LAN 4-port - VGA Extender port - 2x USB Extender
port - 1 x Patchcord FO, 5
meter - 1 x Patchcord Cat
5E UTP, 5 meter
2. POP / BTS
Simulator x1 - POP/BTS Simulator
Micro-controller
Board - Keypad & LCD
Display Micro
controller Board, ISP - LCD Display Panel
20 x 4 - Keypad 4 x 4 - Router Board - Manageble Switch - 3G Wireless Access
Point Router - 3G / 4G Modem
(SIM card not
included) - 3x Media Converter - Switching Power
Supply - On/Off Switch - ISP Simulator Box:
Iron Plate + Acrylic
3. Mini Tower
Simulation Module
x1 - 4 x Iron Mini Tower
framework - 1 x Mini Antenna
Sectoral: Plastic +
Laser Diode - 3 x Mini Antenna
Parabolic: Plastic +
Photo Diode
4. Other Device x3 - 15.6” LED Monitor - Keyboard & Mouse
5. WAN Trainer Table
x3 - Multiplex + Acrylic - Hydraulic Spring - Dimension: P=
120Cm, L=60Cm,
T=18Cm
6. WAN Trainer Table
Leg x3 - Material: Iron - Dimension: P=
120Cm, L=60Cm,
T=57Cm
7. Modul
Pembelajaran dan
Manual x1 - Petunjuk
Penggunaan (A4
Printed Book) - Modul
Pembelajaran (A4
Printed Book)
