Single Phase Power Quality Analyzer

Untuk mendiagnosa daya/ tenaga listrik berjenis single phase.

Voltage AC/ DC 10V- 1000V ± 0.5%
AC Current (A) AC 10-1000A ± 0.5%
Frequency 40 - 7OHz ± 50 mHz
Power > 15%S ± 1%
Power Factor 0 ~ 1.0 ± 0.02
Energy 0-9999 MWh ± 1.5 %rdg
Crest Factor 1-10 ± 5%
Voltage Harmonics or Inter Harmonics:
Um ≥ 3% Udin (1-51th, step 0.5th) ± 5% Urms / ± 0.15% Udin Current Harmonics or Inter Harmonics
Im ≥ 10% I f.s (1-51th, step 0.5th) ± 1% lrms / ± 0.5% f. s.
Power Harmonics: (1-51th, step 1th)
Transients : ±6000V Peak,
F sample = 2 MHz ± 5% Rdg / ± 5% Fs
Dips Swell & Interntpt: 0-1000V
AC Udin ± 1%
AC Inrush Current: 10-1000A ± 1% f.s
Resistance: 600A-60MA ± 1.0%
Capacitance : 60 nF – 600 µF ± 4%
