Sistem Pelatihan Teknologi Dasar Manajemen Air
Peralatan untuk
meningkatkan
kompetensi siswa
dalam mengoperasikan,
merawat dan
memperbaiki sistem
penjernihan air,
distribusi air,
pengolahan air limbah. Satu set harus terdiri
dari :
1 set PLC starter kit
yang dilengkapi dengan
PC interface.
1 Software package
sebagai media untuk
memberi parameter
nilai ke sistem
hardware dan untuk
itu diperlukan juga
koneksi ke PC Interface
1 unit Water supply
tank/ground water
(tank volume: 30 l) with
pipe connection
adapter, submersible
pump, float switch
1 unit Water
purification station,
fully assembled, wired
and tested.
Main components 3 l
tank, including an
overflow rim, capacitive
proximity sensor, float
switch, impeller flow
sensor, pressure sensor
, 2/2-way solenoid
valve, non-return valve,
electric connection
board, aluminum
profile plate.
1 unit chlorine
measurement package,
equipped with a
dropping funnel, a
membrane-covered,
amperometric
measuring cell and an
indicator that can be
parameterized. The
measuring cell
functions within an
operating range of 4 to
9 pH.
1 Power supply unit 24
V DC
