DETAIL PRODUK
Tensile Tester
Kompetensi Keahlian :
Deskripsi :
Untuk menguji kekuatan tarik benda logam/specimen.
Loading system: Closed-loop micro computer controlled digital servomechanism
Maximum capacity: approx. 5kN
Effective test width: approx. 420mm
Crosshead Stroke: approx. 1100mm
Effective stroke: approx. 690 mm
Crosshead Speed: approx. 0,0005- 1000mm/ min
Crosshead speed accuracy : ± 0.1%
Crosshead random speed : approx. 0.0001mm/min step in crosshead speed range
Crosshead speed and load capacity: Maximum load capacity infull speed range
Crosshead return speed: approx. 1000mm/ min or 500mm/ min
Load Measure ment Accuracy : ± 0.5% of reading (within range of 1/1 - 1/500 of load cell rating)
Load range: Fully automatic range switching (up to 128 folds)
Sampling speed: approx. 1msec
Safety function for overload : Provided
Loading system: Closed-loop micro computer controlled digital servomechanism
Maximum capacity: approx. 5kN
Effective test width: approx. 420mm
Crosshead Stroke: approx. 1100mm
Effective stroke: approx. 690 mm
Crosshead Speed: approx. 0,0005- 1000mm/ min
Crosshead speed accuracy : ± 0.1%
Crosshead random speed : approx. 0.0001mm/min step in crosshead speed range
Crosshead speed and load capacity: Maximum load capacity infull speed range
Crosshead return speed: approx. 1000mm/ min or 500mm/ min
Load Measure ment Accuracy : ± 0.5% of reading (within range of 1/1 - 1/500 of load cell rating)
Load range: Fully automatic range switching (up to 128 folds)
Sampling speed: approx. 1msec
Safety function for overload : Provided
