Theodolite
● TELESCOPE
Length of Telesoope : 156mm
Image : Erect
Clear objective aperture : 45mm
Magnification : 30X
Resolving Power : 3.5''
Angle of field of view : 1°30'
Shortest focusing distance : 1.3m
Stadia multiplying constant : 100
Stadia additive constant : 0
Angle Measurement
Method : Raster Incremental/Absolutely
● CODE
Detecting :
Horizontal : Double
Vertical : Single
Minimum Reading : 1"/5"
Accuracy : 2"
Display Panel : Double Face
● COMPENSATOR
Tilt Sensor : Yes
Range of compensator : ±3'
Output Interface
Communication Standard : RS232C
EDM Interface : Yes
Date Output Interface : Yes
● PLUMMET
Accuracy of plummet : ±1mm
● BASE
Base Model : Separated
● POWER
Battery : Chargeable battery / four AA alkaline
Working Time : About 20 Hours
Level Sensitivity
Sensitivity of Long Vial : 30"/2mm
Sensitivity of Bubble : 8"/2mm
● OTHER
Temperature : -20°C~+50°C
Net Weight : 4.8kg
Panel Display : Dua sisi (Double Face)
Dilengkapi dengan sistem pengaman dan
pengaturan sudut.
Material : Tahan karat dan tahan lama.
Kelengkapan : Termasuk tripod
Bahan : Tahan terhadap cuaca ekstrem Mudah
digunakan dan dibawa.
