DETAIL PRODUK
Trainer Operational Amplifier (Op-Amp)
Kompetensi Keahlian :
Deskripsi :
Digunakan untuk pelatihan mengenai operational amplifier (op-amp).
Basic Linear Amp
Differentiator and Integrator
Voltage and Current Circuit
Non-Linear Signal Processing
Generator
Active Filter
Bread Board:
Socket Strip(630 holes) : 2pcs
Bus Strip(100 holes); 3pcs
Technical parameters:
DC Output: 5/6 V, 9/12/15V (Dual Output)
Decade Capacitor: 0.001 - 0.1 µF (2 digits)
Prog. Resistor : 10 kΩ - 1.5 MΩ (2 - BCD)
Variable Resistor : 1/100 kΩ (2ea)
Current : 0 ~ 10mA / 100 mA(2 ranges)
Protection: DC overload alarm dan indication
Speaker: approx.8Ω, 1W
Input Voltage : AC 220 V, 50/60 Hz
Basic Linear Amp
Differentiator and Integrator
Voltage and Current Circuit
Non-Linear Signal Processing
Generator
Active Filter
Bread Board:
Socket Strip(630 holes) : 2pcs
Bus Strip(100 holes); 3pcs
Technical parameters:
DC Output: 5/6 V, 9/12/15V (Dual Output)
Decade Capacitor: 0.001 - 0.1 µF (2 digits)
Prog. Resistor : 10 kΩ - 1.5 MΩ (2 - BCD)
Variable Resistor : 1/100 kΩ (2ea)
Current : 0 ~ 10mA / 100 mA(2 ranges)
Protection: DC overload alarm dan indication
Speaker: approx.8Ω, 1W
Input Voltage : AC 220 V, 50/60 Hz
Tag:
#DAK Alat SMK 2023
Anda menginginkan produk ini?
Hubungi Kami Sekarang
