VSAT IP
Antena (Dish) - Ukuran Antena:
1.2 meter, 1.8
meter, atau 2.4
meter (tergantung
lokasi dan
kebutuhan
bandwidth) - Material:
Aluminium atau komposit
fiberglass - Polarisasi: Linear
atau Circular - Gain Antena: 37
dBi hingga 45 dBi
BUC (Block Up
Converter) - Daya Output: 2W,
4W, 8W, hingga
20W (tergantung
pada kebutuhan
uplink) - Frekuensi Uplink:
14.0 GHz – 14.5
GHz (Ku-Band)
atau 5.85 GHz –
6.425 GHz (C
Band)
LNB (Low Noise
Block
Downconverter - Frekuensi
Downlink: 10.7
GHz – 12.75 GHz
(Ku-Band) atau
3.4 GHz – 4.2 GHz
(C-Band) - Noise Figure: ≤ 1
dB - Gain: 60 dB – 65
dB
Modem VSAT IP - Standar: DVB-S2 /
DVB-S2X untuk
downlink dan
TDMA atau SCPC
untuk uplink - Data Rate: Hingga
100 Mbps
(downlink) dan 10
Mbps (uplink) - Interface: Ethernet
(RJ-45) - QoS Support:
Untuk pengaturan
prioritas data (VoIP, Video
Streaming, dll.)
Power Supply - Input Power: 110V - 240V AC
Power Consumption:
30W hingga 200W
