Welding X-ray Testing Equipment

SPESIFIKASI :

• Max. penetration thickness (A3 steel) 40mm
• Double-face lead foil intensifying screen Pb approx. 0.03 Focal distance approx. 600mm,
• Exposure time approx. 5 minutes negative film, dark room processing
• Developing time approx. 5 minutes Negative film blackness ≥1.5 Power supply AC 220V±10% / 50-60Hz
• Power capacity approx. 2.5 Output voltage 150-250
• Output current approx. 4mA Wave range±1% Focus size approx. 2.0×2.0
• Ray radiation angle45+5º
• sensitivity approx. 1.8% X ray controller
• X ray controller dimension approx. (mm) 360×360×150
• X ray generator size (mm) approx. 320×320×630
• Working pressure 0.34-0.45Mpa
• Cooling way Forced air cooling Isolation method SF6 gas
