Basic Electronics Trainer

  • Input power: Single phase three wire AC220V±10% 50Hz;
  • Output parameters: 2 way DC +1.25~+30V/0.8A; DC±5V/1A, DC±12V/1A; 2 way AC 7.5V, 2 way AC 15V; Compatible with independent winding and neutral axle output
  • Protection measures: AC 220V, safety socket & safety terminal output Capacity:<1KVA Configuration list: Training platform AC220V main control power box AC220V power box Voltage stabilized power supply module I Adjustable DC voltage stabilized power supply module AC power supply Signal generator module Measuring instrument module Mask plate hanging line experiment module Analog circuit experiment box 14P Digital chip module 16P Digital chip module 18P Digital chip module 20P Digital chip module Comprehensive test box module Test line and power line Terminal test line(K2 and K3), Power line Manual book CD Electronic chip
