DETAIL PRODUK

Basic Principle of Digital Technology and Electronics

Kompetensi Keahlian :

Deskripsi :

Minimal Konfigurasi 1 unit power supply unit input 1 x approx. 220 V AC, 50/60 Hz, output : 1 unit Universal patch panel 1 set component for electrical engineering/electronics contains all of the components for carrying out basic tests for direct current technology, 29 resistors 2W, 1 Unit coil: approx. 100 mH, 7 Unit diodes: 1x AA118, 6x 1N4007, 2 Unit Zener diodes: 1x ZPD 3.3, 1x ZPD 10, 2 Unit LEDs: 1x blue, 1x red/green, 1 Set bulb: approx. 12 V 62 mA, 1 Set toggle switch, 1 Set Diac: DB3, 1 Set mounted transformer: 2 coils with approx. 600 windings, 1 coil with approx. 200 windings, 1 separable core, retainer for transformer core 6 Unit transistors: 1x BC 140-16, 1x BC 547B, 1x BC 160-16, 1x BC 140-16, 1x 2N 3820, 1x FET 2N 3819, 1x 2N 2647, 1x BS 250 1 Unit thyristor 1 Unit triac 1 Set compact unit of Voltage supplies and squarewave generator in one, suitable for all tests on digital and control technology 1 set components of digital technology contains all of the components for carrying out basic tests on digital technology, in housings compatible with the 19 mm safe technology plug system. Consist of : 1 Set inverter (3 inverters, 3 Schmitt) trigger,1 Unit AND with 2 inputs, 1 Unit OR with 2 inputs, 1 Unit NAND with 2 inputs, 1 Unit NOR with 2 inputs, 1Unit XOR with 2 inputs, 1 Unit AND with 4 inputs, 1 Unit OR with 4 inputs, 1 Unit hex switch (2-way), analogue source approx. 0 – 5 V, 10L resistor,

Anda menginginkan produk ini? Hubungi Kami Sekarang
