Four Post Lift Alignment

SPESIFIKASI :

• Cylinder Adjustable
• ABS control box, 24v low voltage control system
• Hydraulic hose and cable protection system
• Single side manual lock release
• Heavy duty cables
• Top limit switch
• Aluminum motor with cooling fan
• Lifting capacity : approx. 5000 kg
• Height : 130 mm
• Lifting Height : approx. 1850 mm
• Column Height : approx. 2225 mm
• Width between platforms : approx. 928 mm
• Total width : approx. 3120 mm
• Total length excl. drive on ramps : approx. 4950 mm
• Drive on ramps : approx. 600 mm
• Power of motor : approx. 3.0 kw
• Oil Pressure : approx. 18 MPa
• Power Supply : 220 v
• Lifting time : approx. 50 s
• Lowering Time : approx. 40 s
