Fuel Injection Control Board System

Untuk mempelajari kinerja sistem injeksi elektronik pada engine bensin dilengkapi dengan simulasi deteksi kegagalan sistem

Composition : Fuel Tank, Fuel Pump, pressure regulators, ECU, Injector, fan, crank gear, cam gear, tester for fuel injection

1) Ignition circuit : Coil, ignition plug, air intake

2) Sensor : Temperature sensor, oxygen sensor, air flow sensor, air temperature sensor, an engine temperature sensor, exhaust gas sensor, crank sensor and a cam sensor, Power supply, Sensor pengukuran bahan bakar

Panel kontrol dengan ruang penyimpanan tipe kabinet.

Auto Fault Function

Training Contents Measure the waveforms and check the changes according to RPM speed.

Manual Book

Modul Gasoline Fuel Injection Control System
