Gasoline Emission Analyzer

SPESIFIKASI :

• Measurement: NDIR (NonDispersive infrared) and electronic
  • CO (Carbon Monoxide)
  • HC (Hydrocarbons)
  • CO² (Carbon Dioxide)
  • O² (Oxygen)
  • LAMBDA & AFR (Air/Fuel Ratio)
• Technical Data
  • CO measurement range : 0- 9.999% with 0.01% res.
  • HC measurement range : 0-9999 ppm with 1 ppm res.
  • CO² measurement range : 0- 20.0% with approx. 0.01% res.
  • O² measurement range : 0- 25.00% with approx. 0.01% res.
  • LAMBDA range : 0-2.000% with approx. 0.01% res.
  • AFR range : 0-99.0 with approx. 0.1 res.
• Microprocessor control
• Automatic zero and span adjustment
• Full digital display visible in any light
• LED indicators for all functions
• Membrane switches
• Serial PC Interface
• Fast response time and low drift
• Automatic calibration
• Software supported gas calibrating procedure
• Response time : 10sec. approx.
• Pre -heating time : 3-8min. approx.
• Power supply : 110 / 220 / 240Vac 50/60Hz
