Proximity Sensor Training Set
Digunakan sebagai perangkat untuk mengetahui karakterisktik berbagai sensor berdasarkan jarak benda terhadap sensor.
Input power : AC220V/380V, 50 Hz/60 Hz
Turn source : 0 - 200 r/min (adjustable)
Part List:
Workbench
Testing object box (Photoelectric, magnetic, capacitance, inductance, ultrasonic, current sensors detection medium, etc.)
Position slide
Measuring scale
Optical fiber sensor(correlation)
Optical fiber sensor(Diffuse Reflectance)
Indicate and buzzing unit
Electromagnetic induction proximity sensor
Small, long distance detection and amplifier built-in type photoelectric sensor (Launcher)
Small, long distance detection and amplifier built-in type photoelectric sensor (Receiver)
Optical fiber amplifier
Mirror reflecting photoelectric sensor
Mirror reflecting photoelectric sensor reflecting unit
Small, long distance detection and amplifier built-in type photoelectric sensor (Diffuse type)
Photoelectric sensor M18
Inductive proximity sensor M12
Inductive proximity sensors M18 flush type
Inductive proximity sensors M18 exposed type
Capacitive Proximity Sensor M18
Power module 24VDC
PC module
PC software
Training manual
Test cable K3
Experiment Module
