                        SPII Compact Wellhead
Compact design saves space and permits the use of smaller platforms at a reduced cost; Nominal size
9”, 11”, 13-5/8” or 18-3/4 and pressure rating of
5,000 psi or 10,000 psi; Available in 2 or 3 stage
hanger systems; “WQ” Quick connector on
housing top connection; Casing programs offer flexibility and can be easily changed on site; Fluted
mandrel-type hangers for effective cementing flow-by; Mandrel-type hangers offer complete BOP control, eliminating work under BOP stack and enhancing safety; Internal lockdown for hangers; Same pack-off for all sizes of mandrel hangers; Elastomeric and metal seal assemblies areinterchangeable; Design based on field-proven and fully tested technology; Enhanced safety with minimum through-wall penetrations; Cold cut option is available for emergency purposes; Designed to meet API 6A, latest edition to PSL 1-4, Temperature Rating 0o350o F and Material Classification AA-HH meet NACE requirements.
