VHF Transceiver
- General: Frequency Stability: ±10ppm; Frequency Control: PLL; GPS data sentences can be received: RMC, GGA, GLL, GNS;
- Transmitter: Frequency: 156.025- 157.425 MHz; Output power: approx. 25 W/ 1 W selectable; Spurious & harmonics: better than 2.5 µ W; Modulation Distortion: Less than 4% @ 1kHz for a ±3KHz deviation
- Receiver: Frequency: 156.025- 163.275 MHz; Adjacent CH sensitivity: more than 65dB; Spurious Response: more than 65dB; Intermodulation Rejection Ratio: more than 65dB; Residual Noise Level: more than – 40dB unsquelched; Audio Output Power: approx. 2 W (with 8 Ω at 10% distortion), approx. 4 W (with 4 Ω External speaker); Compass Safe Distance: 0.5 m (1.5’);
- Include 1.2m VHF Antenna and cable with connector
